AMD Ryzen™ 5 Pro 4650G with Wraith Stealth cooler 11MB 6C/12T

General Specifications

Platform: Desktop

Market Segment: Enthusiast Desktop

Product Family: AMD Ryzen™ Processors

Product Line: AMD Ryzen™ 5 Processors

AMD PRO Technologies: No

Consumer Use: Yes

Regional Availability: Global

Former Codename: "Raphael AM5"

Architecture: "Zen 4"

# of CPU Cores: 6

Multithreading (SMT): Yes

# of Threads: 12

Max. Boost Clock: Up to 5.1GHz

Base Clock: 3.8GHz

L1 Cache: 384KB

L2 Cache: 6MB

L3 Cache: 32MB

Default TDP: 65W

Processor Technology for CPU Cores: TSMC 5nm FinFET

Processor Technology for I/O Die: TSMC 6nm FinFET

CPU Compute Die (CCD) Size: 71mm

I/O Die (IOD) Size: 122mm

Package Die Count: 2

Unlocked for Overclocking: Yes

AMD EXPO™ Memory Overclocking Technology: Yes

Precision Boost Overdrive: Yes

Curve Optimizer Voltage Offsets: Yes

AMD Ryzen™ Master Support: Yes

CPU Socket: AM5

Supporting Chipsets:

• A620
• X670E
• X670
• B650E
• B650

CPU Boost Technology: Precision Boost 2

Instruction Set; x86-64

Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB): AMD Wraith Stealth

Max. Operating Temperature (Tjmax): 95°C

Launch Date: 1/14/2023

*OS Support:

• Windows 11 - 64-Bit Edition
• Windows 10 - 64-Bit Edition
• RHEL x86 64-Bit
• Ubuntu x86 64-Bit
• *Operating System (OS) support will vary by manufacturer.

Connectivity

USB Type-C® Support: Yes

Native USB 3.2 Gen 2 (10Gbps) Ports: 4

Native USB 3.2 Gen 1 (5Gbps) Ports: 0

Native USB 2.0 (480Mbps) Ports: 1

Native SATA Ports: 0

PCI Express® Version: PCIe® 5.0

Native PCIe® Lanes (Total/Usable): 28 / 24

Additional Usable PCIe Lanes from Motherboard

• AMD X670E 12x Gen4
• AMD X670 12x Gen4
• AMD B650E 8x Gen4
• AMD B650 8x Gen4

NVMe Support: Boot, RAID0, RAID1, RAID10

System Memory Type: DDR5

Memory Channels: 2

Max. Memory: 128GB

System Memory Subtype: UDIMM

Max Memory Speed:

2x1R DDR5-5200

2x2R DDR5-5200

4x1R DDR5-3600

4x2R DDR5-3600

ECC Support: Yes (Requires mobo support)

Graphics Capabilities

Integrated Graphics: Yes

Graphics Model: AMD Radeon™ Graphics

Graphics Core Count: 2

Graphics Frequency: 2200 MHz

USB Type-C® DisplayPort™ Alternate Mode: Yes

Product IDs

Product ID Boxed: 100-100001015BOX

Product ID Tray: 100-000001015

Key Features

Supported Technologies:

• AMD EXPO™ Technology
• AMD Ryzen™ Technologies
