| HARDWARE |
| Standards |
IEEE 802.3 (10-Base T), 802.3u (100-Base TX) |
| Protocols |
NAT, PPPoE, NTP, SMTP, HTTP, TFTP, DHCP, TCP/IP, PAP, CHAP, RIP1, RIP2, DDNS |
| WAN |
1 x 10/100Mbps port (Internet) |
| LAN |
4 x 10/100Mbps Auto-MDIX ports |
| DMZ |
1 x 10/100Mbps Auto-MDIX port |
| LED Indicators |
Unit: power, status, PPPoE LAN ports/DMZ port: link/act, 100 |
| Power Adapter |
12V DC, 800mA |
| Dimensions (L x W x H) |
170 x 147 x 27 mm (6.7x 5.8 x 1.06 inches) |
| Weight |
0.6 kg( 20.8 oz.) |
| Temperature |
- Operating:0˚ to 40˚ C (32˚ to 104˚ F)
- Storage: -10˚ to 70˚ C (14˚ to 158˚ F)
|
| Humidity |
- Operating: 0 % ~ 80 % (non-condensing)
- Storage: 0% ~ 95% (non-condensing)
|
| Certifications |
FCC, CE, VCCI |
| ROUTER |
| Firewall |
NAT firewall, email alert and logs, SPI firewall |
| Security |
URL filter, access control, password protection |
| VPN (IPSec) |
MD5-HMAC/SHA1-HMAC authentication, DES-CBC, 3DES-CBC encryption, Internet Key Exchange, Manual Key Negotiation |
| VPN Tunnels |
70 (IPSec), 10 (PPTP) |
| VPN Pass-Through |
IPSec, PPTP, L2TP (100 Sessions) |
 |
| PACKAGE CONTENTS |
- TW100-BRV304 (v2.1R)
- Multi-Language Quick Installation Guide
- CD-ROM (User's Guide)
- Power Adapter (12V DC, 800mA)
|
